Prototyping AI Voice Orchestration with Azure Communication Services and Azure AI Voice Live

Prototyping Voice Orchestration

I’ve started an early prototype to explore AI-driven orchestration of live voice interactions. The vision is a voice front door that listens, classifies, and routes requests automatically, while handing off smoothly to humans when needed.

Unlike a single monolithic agent, this architecture separates the telephony, orchestration, and AI speech layers.

The Architecture in Layers

• Phone Network + ACS Front End
  Calls enter through a PSTN number anchored in Azure Communication Services (ACS).

  • Call Automation handles signaling and events.
  • Media Streaming streams audio via WebSockets for real-time processing.

• Orchestration App (FastAPI)
  A Python FastAPI application running in Azure Container Apps.

  • Hosts the Coordinator Agent (classifies intent with a RAG query to Azure AI Search).
  • Runs the External Operations Agent (integrated with 3rd Party MCP) and the Internal Operations (integrated with Internal Operations MCP).
  • Applies policies and routes each call domain appropriately.
  • Handles human-in-the-loop escalation when confidence is low or policy requires it.

• Azure OpenAI Voice Live
  Provides ultra-low-latency speech-to-speech AI.

  • Can be configured in Agent Mode (agent defined in Azure AI Studio).
  • Or can act as a speech front end, invoked by the Orchestration App as one of its services (agent-to-agent).
  • Converts caller audio to text, runs reasoning, and streams back voice responses.

• MCP Servers
  Each domain agent accesses external systems through Model Context Protocol servers.

  • External Ops → 3rd Party Platform Support MCP (work orders, assets).
  • Internal Ops → Internal Operations MCP (ServiceNow, Jira SM).
  • MCPs isolate secrets and standardize tool contracts.

• Observability Layer
  Telemetry, logging, and FinOps metrics captured with Azure Monitor, App Insights, and Log Analytics.

Challenges

• Splitting responsibilities: ACS handles telephony, Voice Live handles speech, but the orchestration logic (agents + routing) lives in the FastAPI app. That means designing clean interfaces and avoiding duplicated logic.
• Agent-to-agent calling: Do we let Voice Live run its own agent, or should the Coordinator Agent call Voice Live as a sub-agent? This is still an open design choice.
• Latency: Orchestration adds hops; tuning is needed to keep round-trip under a second.
• Tool integration: MCP servers must be hardened and trustworthy, since they front vendor APIs.
• Learning loop: Capturing unresolved calls for future training without storing unnecessary PII.

Milestones

Milestone 0 – Foundations

• Gather requirements with stakeholders.
• Define system boundaries (telephony, orchestration, AI, MCPs).
• Design architecture diagrams (call flow, agent orchestration, MCP layers).
• Establish ecosystem: repos, CI/CD pipeline, dev/test ACS number, Key Vault setup.

Milestone 1 – End-to-End Skeleton

• Stand up ACS Call Automation + Media Streaming.
• Connect FastAPI orchestration app.
• Pass a simple audio call through → Coordinator Agent → dummy MCP server → return canned response to caller.
• This “wiring test” proves ACS, media handling, orchestration loop, and MCP integration are functioning together.

Milestone 2 – Coordinator and Routing

• Implement Coordinator Agent with RAG query to Azure AI Search.
• Route calls to External Ops Agent, Internal Ops Agent, or Human in the Loop based on classification.
• Log routing decisions and confidence scores.

Milestone 3 – Domain Agents with MCP Integration

• External Ops Agent integrated with 3rd Party MCP (work orders, assets).
• Internal Ops Agent integrated with Internal Operations MCP (incidents, service desk tasks).
• Verify round-trip tool call flows.

Milestone 4 – Human in the Loop & Case Bundling

• Warm transfer to call center/IT when confidence is low or policy triggers.
• Package Case Bundle with last transcript, entities, and tool attempts.

Milestone 5 – Observability and FinOps

• Logging (latency, ASR accuracy, automation vs HITL rate).
• Dashboards for cost, performance, and error rates.

Milestone 6 – Testing, Documentation, and Handoff

• System testing across scenarios (happy path, error handling, fallback).
• User acceptance / operational readiness.
• Documentation: architecture, agent contracts, runbooks.
• Handoff to client operations team.

Diagrams

Architecture Overview

Call Sequence

References

• Azure Communication Services
• Azure AI Voice Live
• Azure AI Agents
• Model Context Protocol
